Skutečné rozměry povrchu stolu: 1 200 x 1 200 mm
Výška boční desky stolu: 150 mm
* Všechny nosnosti jsou vypočteny na základě statického zatížení.
* Doporučujeme volitelnou sadu podpěrných nohou TMLB120A.
Couldn't load pickup availability
The new heavy-duty table line from BuildPro, it features 5 sides fitted with 16 mm diameter boreholes for more versatility and expandability than before. Maintaining industry-leading requirements for flatness, squareness, and dimensional accuracy.
Available in standard and nitrided tabletop finishes.
| Hole Diameter: |
| 16 mm |
| Grid Pattern: |
| 50x50 mm |
| Tabletop Size: |
| 1200x1200 mm |
| Tabletop Thickness: |
| 12 mm |
| Surface Hardness: |
| 58-62 HRC (top) |
| Coefficient of Friction: |
| 0.37 |
| Optional Finish: |
| Nitrided |
| Nitriding Case Depth: |
| 0.01 - 0.02 mm |
| Table Flatness: |
| 0.3 mm / 1,000 mm |
| Tabletop Side Height: |
| 150 mm |
| Capacity: |
| 680 kg per Leg |
| Gross Weight: |
| 315 kg |
Each table plate can be removed and flipped 180 degrees to expose a new working surface if the top side has been damaged or worn down.
Table Flatness: 0.3 mm / 1,000 mm
Hole Spacing: 50 mm ±0.0254
Hole Diameter: 16 mm
Plate Thickness: 12 mm ±0.1016
Our five-sided tables feature a 138 mm side plate combined with the top plate to create a 150 mm height.
Alpha table side plates feature an extended 5 borehole pattern for added precision and adjustability.
All top and side plates are constructed from heat-treated steel, hardened to 58-62 HRC (top) and 50-55 HRC (side), and finished with a nitride coating with a case depth of 0.01 - 0.02 mm.
Fully Assembled
Plate Frame
It depends on where you are. Orders processed here will take approx. 5-7 business days to arrive.
Yes, we do. Please visit this link for more information about shipments outside EU.
If you need to return or exchange an item, please contact us with your order number and details about the product you would like to return or exchange. We will respond with instructions for how to proceed from there. Returns will be accepted within 30 days of receiving it. No returns on tools or any components that have been modified outside of Strong Hand Tools.
This product is manufactured under the supervision of Strong Hand Tools at:
Valtra (Shanghai) Machinery Co., Ltd.
Address: 605 Huabo R, Huating, Jiading, 201816 Shanghai, China
E-Mail: contact@stronghand.eu
European Manufacturer: No
